Ansible 시작 [ 공개키 / 개인키 ]

▶ server / node1 ~ 3 에 공통적으로 추가

[root@control ~]# useradd devops
[root@control ~]# passwd devops

echo "devops ALL=(ALL) NOPASSWD: ALL" > /etc/sudoers.d/devops





▶다른 컴퓨터에서 telnet 서버 다운로드

>> root  권한이 필요하다

[devops@control ~]$ ssh devops@192.168.110.20 'yum -y install telnet-server'
devops@192.168.110.20's password:
Loaded plugins: fastestmirror
You need to be root to perform this command.

[devops@control ~]$ ssh devops@192.168.110.20 'sudo yum -y install telnet-server'
devops@192.168.110.20's password:
Complete!



# 같은 계정이므로 devops 빼고 가능

[devops@control ~]$ ssh 192.168.110.20 'sudo yum -y install telnet-server'



▶공개키 생성하여 반복 작업 최소화



▶devops 로그인하여 공개키 설정

(pass phrase 를 입력 안하도록 설정)

## ssh-keygen 이후는 엔터로 넘어간다

[devops@control ~]$ ssh-keygen
Generating public/private rsa key pair.
Enter file in which to save the key (/home/devops/.ssh/id_rsa):
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in /home/devops/.ssh/id_rsa.
Your public key has been saved in /home/devops/.ssh/id_rsa.pub.
The key fingerprint is:
SHA256:qp9nnNU+IxJffaf0IntN7QIgVSSKMr0Q/jX2iUtHEW0 devops@control.example.com
The key's randomart image is:
+---[RSA 2048]----+
|    .     +=o    |
|   . o . ..oE    |
|    = o =...     |
|     = +.=..     |
|      o S.+o .  .|
|       o.o. + o =|
|      ...= o o B.|
|     . .* o = = +|
|    ..oo . ..* o |
+----[SHA256]-----+



## 키로 인증이 되었다

[devops@control ~]$ cd .ssh
[devops@control .ssh]$ ls
id_rsa  id_rsa.pub  known_hosts
[devops@control .ssh]$ ll
total 12
-rw-------. 1 devops devops 1675 Feb  6 07:42 id_rsa
-rw-r--r--. 1 devops devops  408 Feb  6 07:42 id_rsa.pub
-rw-r--r--. 1 devops devops  176 Feb  6 07:35 known_hosts

[devops@control .ssh]$ ssh-copy-id node1.example.com

ssh-copy-id 명령어가 없을 때 사용했었던 명령어
[devops@control ~]$ scp ~/.ssh/id_rsa.pub devops@node1.example.com
:/home/devops/.ssh/authorized_keys
한개의 만든 공개키를 다 같이 쓰는 것


[devops@control .ssh]$ ssh-copy-id node2.example.com >> 실행
[devops@control .ssh]$ ssh-copy-id node3.example.com >> 실행

/usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/home/devops/.ssh/id_rsa.pub"
The authenticity of host 'node1.example.com (192.168.110.20)' can't be established.
ECDSA key fingerprint is SHA256:dJUzL1q0e45rkPCjG9Gvii2kqv9JNMsSSlSUzpoh1Ts.
ECDSA key fingerprint is MD5:90:fd:e8:8b:48:a2:74:2e:10:33:43:2f:53:1c:4a:ed.

Are you sure you want to continue connecting (yes/no)? yes

/usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any
that are already installed
/usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed --
if you are prompted now it is to install the new keys
devops@node1.example.com's password:

Number of key(s) added: 1

Now try logging into the machine, with:   "ssh 'node1.example.com'"
and check to make sure that only the key(s) you wanted were added.



▷이후에는 인증없이 바로바로 가능

[devops@control .ssh]$ ssh node1.example.com 'sudo yum -y install telnet'
[devops@control .ssh]$ ssh node2.example.com 'sudo yum -y install telnet'
[devops@control .ssh]$ ssh node3.example.com 'sudo yum -y install telnet'





▶ 공개키와 개인키

공개키	개인키
누구나 받아서 사용할 수 있는 키	공개키로 암호화해서 보낸 메세지를 해석할 수 있는 유일한 키
서명을 해독하는 것이 공개키	부인 방지를 위해 사용 ( 서명 )



▶ 공개키

[root@control ~]# ls /etc/pki/rpm-gpg/RPM-GPG-KEY-CentOS-7
/etc/pki/rpm-gpg/RPM-GPG-KEY-CentOS-7



▶FingerPrint

[root@control ~]# ls /home/vagrant/.ssh
authorized_keys  known_hosts



▶과정 해설

[devops@control .ssh]$ pwd
/home/devops/.ssh
[devops@control .ssh]$ ssh-keygen -t rsa
Generating public/private rsa key pair.
Enter file in which to save the key (/home/devops/.ssh/id_rsa):
/home/devops/.ssh/id_rsa already exists.
Overwrite (y/n)? y
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in /home/devops/.ssh/id_rsa.
Your public key has been saved in /home/devops/.ssh/id_rsa.pub.
The key fingerprint is:
SHA256:A90yw9V6mwErbqQVMMmyLv0OG6OocOEJzzMhu/I/pKk devops@control.example.com
The key's randomart image is:
+---[RSA 2048]----+
|     .oo  ..     |
|    . o+.o. .    |
|     o. *..+     |
|    .  .++o o    |
|o oo   =S. . +   |
| B.++ . o.  o    |
|o O=+. .         |
|o+o+.=.          |
|Eoo.oo.          |
+----[SHA256]-----+
[devops@control .ssh]$ ls
id_rsa  id_rsa.pub  known_hosts
개인키 / 공개키 / fingerprint

known_hosts >>> finger print
접속할 때마다 상대 장비에 보내주고
비교해서 확인

[devops@control .ssh]$ ssh node1.example.com
devops@node1.example.com's password:
Last login: Tue Feb  6 09:05:35 2024 from 192.168.110.10

>>>> 정상적으로 finger print로 로그인 했다
(이전에 접속 했으면 바로 password입력)

[devops@control .ssh]$ rm known_hosts
[devops@control .ssh]$ ls
id_rsa  id_rsa.pub
[devops@control .ssh]$ ssh node1.example.com
The authenticity of host 'node1.example.com (192.168.110.20)' can't be established.
ECDSA key fingerprint is SHA256:dJUzL1q0e45rkPCjG9Gvii2kqv9JNMsSSlSUzpoh1Ts.
ECDSA key fingerprint is MD5:90:fd:e8:8b:48:a2:74:2e:10:33:43:2f:53:1c:4a:ed.
Are you sure you want to continue connecting (yes/no)? yes

만약 전에 접속했었는데 또 물어본다면, 뭔가 문제가있다 ( 보안 )



▶ 아파트 들어갈 때에 카드로 들어갈 때 = 공개키 인증

▶ 비밀번호 넣고 들어갈 때 = 개인키 인증

>> 오히려 카드키로 들어가는게 더 안전할 수도 있다



https://jamesmccaffrey.wordpress.com/2020/07/29/the-diffie-hellman-key-exchange/

The Diffie–Hellman Key Exchange

>> 공격자가 알 수 있는 색은 노랑과 주황 초록

>> 파랑과 빨강은 모른다

>> 최종 결과는 똑같은 색이 나오므로 그 색을 공통키로 쓴다

>>> 결국 본인들의 암호화 키를 보내주지 않아도 된다
